Arm Barrier

Arm Barrier

Security Barrier

  • Configuration

    Available in widths up to 8m

  • Customisation

    Wide variety of colours

Enquire Now View Range
Arm Barrier

The Arm Barrier is the ideal product to aid with traffic management and is suitable for use in locations such as car parks, airports and traffic control areas.

Heald’s Arm Barrier is available in a wide range of size and finishes to suit any site, offering a simple, efficient solution for automated traffic control. The barriers can be used in conjunction with a variety of Heald products and entry systems such as time clock, proximity cards, keypads etc. Heald also offer a version of the Arm Barrier which can be directly mounted to a trief containment kerb with matching catch posts or pogo options for beam support.

Lockable in the open and closed positions, with an optional skirt available for added security. The boom is manufactured from aluminium tube and finished in white, with red reflective stickers as standard. The barrier moves using a geared motor drive unit via a control panel which includes overload protection, a smart relay and an inverter.

Heald design all their products to be long lasting and enable the easy replacement of serviceable components. We offer support and maintenance packages to all customers to ensure that the consistently high levels of service and protection you expect can be maintained by our specialist team of engineers giving you peace of mind that your security investment is in good hands.

Arm Barrier

Arm Barrier

Arm Barrier

Our Arm Barrier Range

  • Arm Barrier Width: Available in widths up to 8m

    Operating speed: 3 seconds approx.



    Options:

    • Hydra Control
    • LED lights
    Arm Barrier Opt 1

    Data Sheet

Arm Barrier USPs

Previous
Next
1.

Painted high visibility red and white (other colours available upon request)

2.

Low maintenance requirements

3.

Adjustable limit switches for accurate raised and lowered positioning arm

4.

Arm will move through 90° to give vertical rest position of open barrier

5.

Variety of different widths available to secure any size perimeter opening

6.

Can act in a flexible array coupled with Heald’s Hydra system

7.

State of the art energy efficient slow-down and positioning

8.

Motor capable of fast or slow movement

9.

Easy access for maintenance

10.

Surface mounted (bolted) to a concrete base

11.

Available as a trief containment kerb mounting with matching catch posts or pogo options for beam support
